MAKERBASE Gen-L V2.1 Control Board

Note

1. Ensure the positive and negative connection is right before powering.
2. No plugging and removing drivers when powering, otherwise it will easily burn the drivers.
3. No adjusting the driver current when the motors are running.

MAKERBASE Gen-L V2.1 highlights

1. Integrate 2560 and Ramps1.4 to one PCB, easier wiring and more stable.
2. Use high-quality 4-layer PCB.
3. Use Marlin firmware same configuration way as Ramps1.4, it can replace Ramps1.4 directly.
4. Use a special power chip that supports 12V-24V.
5. Support a variety of stepper drivers: 4988, 8825, TMC2208, and TMC2100. (need to buy separately)
6. Available to work with LCD2004, LCD12864, MKS, TFT24/28/32/35/70.
7. Accept 24V input, and reduce the heated bed current to 1/4 which solves the Mosfet heat problem efficiently.
8. Available to connect external large stepper drivers.
9. Retain Servos, AUX-1 and AUX-2 interface of Ramps1.4, provide three 5V output and three 12V output interfaces.

General
Brand	Makerbase
Type	Control Board
Model	Gen-L V2.1
Specification
Support Stepper Drivers	4988, 8825, TMC2208, and TMC2100.
Power Chip Voltage	12V-24V
Available to Work with	LCD2004, LCD12864, MKS, TFT24/28/32/35/70
Weight & Size
Package Weight	0.11kg
Package Size(L x W x H)	12x9x1cm
