OWON CM2100 Clamp Meter

OWON CM2100 highlights

Multiple Measurement Functions

OWON CM2100 20000 count true RMS automatic range clamp meter can measure AC/DC current, AC/DC voltage, resistance, capacitance, diode, etc.

NCV & VFC Function

Also, it has standard non-contact AC voltage sensing (NCV) function, and the VFC mode can filter high-frequency interference signals to ensure accurate measurement data.

Easy to Carry

This clamp meter is designed with a compact size, a function selection knob, and a clear LCD screen, easy to operate and carry.

General
Brand	OWON
Type	Clamp Meter
Model	CM2100
Color	Blue
Specification
AC Current (A): 2.000A / 20.00A / 100.0A
AC Voltage (V): 2.0000V / 20.000V / 200.00V / 600.0V
DC Current (A): 2.000A / 20.00A / 100.0A
DC Voltage (V): 200.00mV / 2.0000V / 20.000V / 200.00V / 600.0V
Resistance (R): 200.0Ω / 2.0000kΩ / 20.000kΩ / 200.00kΩ / 2.0000MΩ / 20.000MΩ / 200.00MΩ
Capacitance (F): 2.000nF / 20.00nF / 200.0nF / 2.000uF / 20.00uF / 200.0uF / 2.000mF / 20.00mF
Frequency (Hz): 200.00Hz / 20.000kHz / 200.00kHz / 2.0000MHz / 20.000MHz
Duty cycle (%): 0.1% - 99.9% (typical: Vrms=1 V, f=1kHz); 0.1% - 99.9% (≥1 kHz)
Display: 20000 counts
Frequency Response: 40Hz - 1000Hz
Auto Ranging: Yes
Date Hold: Yes
Diode: Yes
Continuity Buzzer: Yes
NCV: Yes
VFC: Yes
Zero: Yes
Low-battery Indicator: Yes
Relative Measurement: Yes
Input Protection: Yes
Input Impedance: ≥10MΩ
Overrange Alarm: Yes
On-off Warning: Yes
Jaw Capacity: 17mm
Battery: 2 x 1.5V AAA
Weight & Size
Product Weight	0.2kg
Package Weight	0.31kg
Product Size(L x W x H)	18.2x5.7x3.2cm
Package Size(L x W x H)	20x7x5cm
Package Contents
1 x Clamp Meter
1 x Multimeter Lead
1 x Soft Bag
1 x Bolt Driver
2 x 1.5V AAA Batteries
1 x User Manual
